| 产品类型 | 晶圆名称 | Directional | Reverse Stand-off Voltage | Breakdown Voltage | Leakage Current | Capacitance | Clamping Voltage | Peak Pulse Current | Peak Pulse Power | ESD | 晶圆基本信息 | ||||||
| Vrwm | VBR | IR | Cap | VCL(@IPP) | IPP(8/20us) | PPK(8/20us) | Contact | Air | Wafer Size | Die Size（包含划片道） | Gross Die | 正面金属 | 减薄后厚度 | 背金 | |||
| （V) | （V) | （nA） | （pF） | （V) | （A） | （W） | (kV) | (kV) | |||||||||
| TVS | AC01A | Uni. | 7 | 8 | <500 | 740 | 20 | 135 | 2700 | 30 | 30 | 6'inch | 0.8mm*0.8mm | 25517 | AlSiCu | 150um | Au |
| TVS | AC01AS | Uni. | 7 | 8 | <500 | 650 | 21 | 119 | 2300 | 30 | 30 | 6'inch | 0.72mm*0.72mm | 31542 | AlSiCu | 150um | Au |
| TVS | AC01B | Uni. | 12 | 14.8 | <500 | 375 | 28 | 80 | 2200 | 30 | 30 | 6'inch | 0.8mm*0.8mm | 25517 | AlSiCu | 150um | Au |
| TVS | AC01BS | Uni. | 12 | 14.8 | <500 | 300 | 30 | 55 | 1400 | 30 | 30 | 6'inch | 0.72mm*0.72mm | 31542 | AlSiCu | 150um | Au |
| TVS | AC01C | Uni. | 5 | 7 | <500 | 980 | 20 | 140 | 2700 | 30 | 30 | 6'inch | 0.8mm*0.8mm | 25517 | AlSiCu | 150um | Au |
| TVS | AC01D | Uni. | 15 | 16.5 | <500 | 330 | 30 | 70 | 2000 | 30 | 30 | 6'inch | 0.8mm*0.8mm | 25517 | AlSiCu | 150um | Au |
| TVS | AC02A | Uni. | 7.5 | 9 | <500 | 1700 | 23 | 240 | 5000 | 30 | 30 | 6'inch | 1.55mm*1.05mm | 9960 | AlSiCu | 150um | AuAs |
| TVS | AC02B | Uni. | 12 | 14.5 | <500 | 950 | 29 | 180 | 5000 | 30 | 30 | 6'inch | 1.55mm*1.05mm | 9960 | AlSiCu | 150um | AuAs |
| TVS | AC02C | Uni. | 15 | 17.5 | <500 | 950 | 34 | 159 | 5000 | 30 | 30 | 6'inch | 1.55mm*1.05mm | 9960 | AlSiCu | 150um | AuAs |
| ESD | AC03BG1 | Bi. | 4.5 | 5.3 | <500 | 14 | 9 | 9 | 70 | 30 | 30 | 6'inch | 0.22mm*0.22mm | 340473 | AlSiCu | 100um | TiNiAg |
| ESD | AC03CG1 | Bi. | 5 | 5.7 | <500 | 9 | 9 | 8 | 60 | 30 | 30 | 6'inch | 0.22mm*0.22mm | 340473 | AlSiCu | 100um | TiNiAg |
| ESD | AC03G1 | Bi. | 3.3 | 3.8 | <500 | 13 | 8 | 10 | 80 | 30 | 30 | 6'inch | 0.22mm*0.22mm | 340473 | AlSiCu | 100um | TiNiAg |
| ESD | AC04BSNG1 | Bi. | 4.5 | 5.3 | <500 | 70 | 9.6 | 37 | 400 | 30 | 30 | 6'inch | 0.4mm*0.4mm | 102706 | AlSiCu | 150um | TiNiAgSn |
| ESD | AC04CSNG1 | Bi. | 5 | 5.7 | <500 | 70 | 9.5 | 36 | 300 | 30 | 30 | 6'inch | 0.4mm*0.4mm | 102706 | AlSiCu | 150um | TiNiAgSn |
| ESD | AC04SNG1 | Bi. | 3.3 | 3.8 | <500 | 70 | 11 | 40 | 350 | 30 | 30 | 6'inch | 0.4mm*0.4mm | 102706 | AlSiCu | 150um | TiNiAgSn |
| TVS | AC05G1 | Bi. | 4.5 | 5.4 | <200 | 900 | 21 | 290 | 6000 | 30 | 30 | 6'inch | 1.55mm*1.05mm | 9960 | AlSiCu | 150um | TiNiAg |
| TVS | AC06G1 | Bi. | 4.5 | 5.3 | <500 | 300 | 18 | 140 | 2500 | 30 | 30 | 6'inch | 0.72mm*0.72mm | 31542 | AlSiCu | 150um | AuAs |
| ESD | AC1LCA | ||||||||||||||||
| ESD | AC4LCAG1 | ||||||||||||||||
